LV Surge Arrester upto 440V for substation protection from lightening and switching overvoltages. LV Surge Arresters provide protection for low-voltage overhead lines, consumer in-house supplies, distribution transformers and other systems. Numerous tests have confirmed durability of the housing, even when exposed to extreme temperature fluctuations and contamination Suitable for indoor and outdoor application Integrated disconnector and 1m line lead. Overhead…
MCS for 25 KV high speed requirements - 20 KN and 24 KN. Raychem Indigenous Modular Cantilever System is designed to support the assembly of overhead power transmission wires — i.e., catenary (1000/1200 kgf tension), contact (1000/1200 kgf tension), and droppers — to transfer the overall bending, transverse, and vertical loads to the mast via insulators. The quintessential cantilever is…
Raychem RPG Medium Voltage (MV) Switchgear Terminations are screened separable cable connectors designed for safe and reliable connection of medium-voltage power cables to switchgear, transformers, RMUs, and GIS equipment. These terminations are compact, space-saving, and engineered for voltage applications up to 36 kV. Key features include: High electrical reliability and operational safety Compact design suitable for modern switchgear panels Available…
Raychem RPG Medium Voltage (MV) Switchgear Terminations are screened separable cable connectors designed for safe and reliable connection of medium-voltage power cables to switchgear, transformers, RMUs, and GIS equipment. These terminations are compact, space-saving, and engineered for voltage applications up to 36 kV. Â Key Points (Summary) Used for terminating MV cables into switchgear panels Compact, space-saving, and highly reliable design…
Raychem Medium Voltage (MV) switchgear terminations are screened separable connectors used to connect power cables to switchgear systems safely and efficiently. They are designed for voltages up to 36 kV and provide reliable insulation, stress control, and compact connections. 🔹 Key Points (Summary) Used for terminating MV cables into switchgear panels Compact, space-saving, and highly reliable design Available in two…
Medium Voltage screened separable connectors for switchgears. Raychem developed screened separable connectors for switchgears which are compact and space saving, having high degree of reliability and safety. These terminations are designed, developed, and tested upto 36 kV for almost all sizes of cables. Switchgear terminations are either OUTER CONE type (suitable for bushings as per EN 50181 for Type A…
Raychem MV Surge Arresters (up to 52 kV) Raychem MV surge arresters (up to 52 kV) are metal-oxide (ZnO), gapless protective devices used to safeguard medium-voltage power systems from lightning and switching overvoltages. They use MOV (metal oxide varistor) technology with no spark gaps, giving fast response and better protection levels. The arresters have polymeric (silicone rubber) housing, which is…
Raychem MV surge arresters are modern, reliable, and efficient devices that protect medium-voltage systems by safely diverting surge currents to ground and preventing equipment damage. Excellent TOV performance. Safe, non-shattering failure in short circuit test Higher energy handling capability Crimped structural construction is light in weight, provides optimal mechanical strength Void free construction and optimum interface sealing achieved by bonding…
MV Surge Arrester upto 45kV for substation protection from lightening and switching over voltages. In past 15 years, almost all high-voltage networks used MO arresters. However, in medium-voltage networks, a substantial number of conventional gapped arresters (SiC resistors and series spark gaps) were installed until a few years ago. Today MO (Metal-Oxide) arresters without spark gaps have gained popularity. Networks…
Overhead line covers for bare conductors. MVLC provides state-of-the-art insulation to help prevent electrical outages. It is designed to insulate existing bare lines without costly conductor replacement expenditures or additional line hardware. MVCC provides high quality electrical insulation and made from non-tracking silicone material suitable for harsh medium voltage outdoor environments. MVCC is suitable for applications up to 25 kV…
🔹 Summary of Raychem MV Surge Arresters (up to 52 kV) Raychem MV surge arresters (up to 52 kV) are metal-oxide (ZnO), gapless protective devices used to safeguard medium-voltage power systems from lightning and switching overvoltages. They use MOV (metal oxide varistor) technology with no spark gaps, giving fast response and better protection levels. The arresters have polymeric (silicone rubber)…
