Cable Reels 3-Phase 400 VAC without Lamp BLCR400E
Bahco Cable Reels 3-Phase 400 VAC without Lamp BLCR400E :
- Industrial 3-phase 400 VAC automatic cable reel for power distribution.
- Equipped with 20 m H07RN-F rubber cable (5 × 1.5 mm²).
- Supports up to 5000 W when fully extended and 2800 W when coiled.
- Features a resettable circuit protection switch covering all three phases.
- IP24-rated for protection against splashing water and solid objects.
- Includes a 145° swiveling wall-mount bracket for flexible installation.
- Automatic rewind mechanism with a ratchet cable stop.
- Suitable for workshops, factories, maintenance areas, and other industrial environments.
- Approximate weight: 11 kg.
Model: Bahco BLCR400E
Application: Safe storage and extension of 3-phase 400 V power cables in industrial settings.
Description
The Bahco Cable Reels 3-Phase 400 VAC without Lamp BLCR400E is a heavy-duty industrial cable reel designed for 3-phase 400 VAC power distribution and cable management. It is commonly used in workshops, factories, maintenance facilities, and industrial installations.
Key Specifications :
| Feature | Specification |
| Model | BLCR400E |
| Voltage | 400 VAC, 3-phase |
| Cable Type | H07RN-F, 5 conductors |
| Conductor Size | 5 × 1.5 mm² |
| Cable Length | 20 m (manufacturer specification) |
| Maximum Power (Cable Extended) | 5000 W |
| Maximum Power (Cable Coiled) | 2800 W |
| Protection Rating | IP24 |
| Mounting | Steel wall bracket, swivels 145° |
| Safety Feature | Resettable circuit safety switch for all 3 phases |
| Weight | Approximately 11 kg |
| Optional Accessory | BPHRSC speed-control adapter |
Features :
- Automatic cable storage and extension system.
- Ratchet cable stopper that can be disengaged when continuous retraction is preferred.
- Industrial-grade rubber cable suitable for demanding environments.
- Built-in safety cut-out to protect connected equipment and wiring.
- Swiveling wall support allows flexible cable routing.
