MCS (Modular Cantilever System)
MCS for 25 KV high speed requirements – 20 KN and 24 KN. Raychem Indigenous Modular Cantilever System is designed to support the assembly of overhead power transmission wires — i.e., catenary (1000/1200 kgf tension), contact (1000/1200 kgf tension), and droppers — to transfer the overall bending, transverse, and vertical loads to the mast via insulators. The quintessential cantilever is lightweight and robust enough to support the current-carrying assembly for semi-high speed and high-speed trains up to 250 km/h. In addition to these functional requirements, ease of maintenance, transportation, handling, and aesthetics have been considered.
Description
- Simple and light in weight – Factory fitted assembly, ready to install , Ease of installation and servicing at site, Low maintenance and onsite inspection
- Structural integrity- Validated for severe static and dynamic loading condition, Designed for high tension OHE lines for high-speed trains
- Corrosion resistant, long service life and reliable
- Suitable at various positions – Push off & pull off, Anti creep, Box , Overlap Arrangements etc
- Best Insulator Technology – Polymeric Insulators providing high mechanical strength combined with polymeric shredded profile making light weight design
- One solution for all variants, different assembly/configurations possible – Pull / Push off for implantation 2.36 m to 3.6 m Anti-creep arrangement Flexibility – box arrangement for yards (1.0m) Stretched length for platform (upto 4.7m) Over
- Ideal for existing and new high-speed Railway lines, DFCC and Metros
| Parameter |
|---|
| Comply with latest RDSO Specification No. TI/SPC/OHE/MCS/0150(08/2015) |
Technical Information
| Sr No | Parameter | Value |
|---|---|---|
| 1. | Line Tension | 20/24/30 kN |
| 2. | Train Speed | 200 Kmph |
| 3. | Span Length | ≤ 72 m |
| 4. | Stagger | Upto 0.3m |
| 5. | Encumbrance | Max. 1.4 m |
| 6. | Implantation/Setting Distance | 2.36 – 3.6 m |
Brand
Raychem RPG
